Pyrotechnic Mild Detonating Cord RDX-Aluminum
Pyroalliance designs and manufactures a complete family of detonation cords dedicated to transmit a pyrotechnic signal, induce a ultra-short time delay or used for structure weakening.
Those can be made of different metallic materials and various explosive types depending on the application requirements.
Pyroalliance has the ability to propose detonating cords with specific plastic coating and/or armoured cladding.
More generally, Pyroalliance delivers complete pyrotechnic chains adapted to its customers’ needs.
They are designed and manufactured under Pyroalliance design authority.
Pyroalliance’s Mild Detonation Cord will equip Ariane 6 and Vega C
Mild Detonating Cord RDX-Aluminum at a glance
Benefits of pyrotechnics
- The Detonation Cord is used to propagate a detonation from one end to the other with an average speed of 7500 m/s. It is highly reliable and inspectable via X-Ray.
Space applications
- Detonating transfer lines
- Frangible joint assembly
Key figures of pyrotechnic performance
| TECHNICAL SPECIFICATIONS | OUR RANGE OF PERFORMANCE |
| DETONATING VELOCITY: | 7000 à 8000 m/s |
| EXTERNAL DIAMETER: | Ø 1.5 to Ø 6mm |
| IGNITION MODE: | Detonation shock |
| OPERATING TEMPERATURE: | Down to -80°C Up to + 100°C |
